Model：BAT54SW-7-F

Manufacturer：NXP

Stocks：800

Describe：BAT54SW-7-F is a surface mount Schottky barrier diode launched by NXP Semiconductors (formerly Philips). It is packaged in SOT-323 (SC-70) and belongs to the ultra-high-speed switching diode series. It is suitable for high-frequency signal processing and protection circuits. Core features Low forward voltage drop (typical value 0.3V @ 10mA) and fast switching speed (reverse recovery time ≤ 5ns). PN junction protection ring design, providing transient voltage and ESD protection, in compliance with RoHS standards. Operating temperature range: -55°C to 150°C, suitable for industrial-grade and automotive electronic applications. Application scenario High-frequency rectification (such as for RF signal detection), polarity protection (to prevent damage to the MCU from reverse voltage). Portable device power management (low-power design suitable for scenarios with limited space).
